05 — CI with `zlens eval`, and what `zlens verify` is for¶

Who this is for: platform engineers wiring ZLens into CI and audits.

What you'll do: gate every pull request on zlens eval, add golden questions of your own, and learn which checks belong in CI and which are local.

Time: 15 minutes.

Setup: a ZLens project tracked in git with at least one certified block that has examples. The Jaffle Shop sample is one; the commands below run in its root.

Why gate on `zlens eval`?¶

zlens eval replays every certified block's examples[].question, plus any cases in eval/*.yaml, through the same router Ask uses, and scores where each question went: to a certified block, to generated SQL, or to a refusal.

It builds the manifest from source in memory, reads no warehouse and calls no model. So it runs on a clean clone: no *.duckdb file, no dbt target/, no dql-manifest.json, and no API key. It exits 1 when a score is below the thresholds you set.

Step 1 — Run it locally¶

npx zlens eval . --min-route-accuracy 1 --min-refusal 1

You should see one line per case, then the scores:

  ✓ [certified] monthly_revenue · How has revenue changed by month?
  ✓ [certified] monthly_revenue · Show monthly gross revenue and number of orders.
  …
  Thresholds
  --------------------------------------------------
  --min-route-accuracy 1  (route accuracy 100%)
  --min-refusal 1  (refusal recall n/a: no case measures this, so it is not applied)

  ✓ PASS — thresholds met.

Thresholds are shares between 0 and 1, so 90% is 0.9. A value outside that range, such as --min-route-accuracy 90, is an error (exit 1). A threshold that no case measures is reported as n/a and is not applied. In the sample, --min-refusal waits for a case with expectRefuse: true, which you add in Step 2.

To run only your eval/*.yaml cases and skip the certified saved queries' own examples, add --no-examples.

When a block example fails¶

A block example is a promise that the question is answered by that certified block. Two common reasons it routes to generated SQL instead:

The question names a member. "Give me the complete profile for Matthew Meyer." asks for one customer. A certified block runs its SQL as written, and customer_profile has no WHERE, so it cannot filter to one customer. Ask answers with generated SQL that uses the block as context. Reword the example ("Show customer profiles with lifetime spend and order history.") or move the question to eval/*.yaml with expectRoute: generated.
The question asks for a measure the block does not output. In "Show monthly gross revenue and orders.", "orders" is not the block's order_count output. A count output answers a question that says "how many", "count", "number of" or "total" ("…and number of orders.").

The failure line shows what happened, for example route expected certified, got generated. --format json adds each case's route reason in trace.

A block that is no longer certified drops its examples from the run, so keep its key questions in eval/*.yaml too (Step 2). For example, if eval/golden.yaml expects How has revenue changed by month? to route to monthly_revenue, and someone changes that block from certified to draft, the case fails with route expected certified, got missing_context and the run ends ✕ FAIL — below configured thresholds. (exit 1).

Step 2 — Add golden cases¶

Video · 0:49Test your answers

npx zlens eval . --init

This writes eval/golden.yaml with commented examples written for the Jaffle sample's blocks. Uncomment the ones that fit, swap in your own block names, and add one case per question your team asks:

cases:
  - name: named customer → generated, filter kept
    question: "Give me the complete profile for Matthew Meyer."
    expectRoute: generated
    expectFilters: ["Matthew Meyer"]

  - name: unanswerable refuses
    question: "What is our employee attrition rate?"
    expectRefuse: true

Each case can set expectRoute (certified, generated, missing_context or research), expectBlock, expectGrain, expectRefuse, the question-plan checks (expectMetricTerms, expectNoMetricTerms, expectFilters, expectNoFilters, expectEvidence) and, for a follow-up, priorQuestion. zlens eval --help lists them all. When Ask gets a question wrong, add the question here before you fix it.

A refused question shows its route as missing_context.

Step 3 — Add the workflow¶

Video · 0:47A check on every pull requestRecorded on 0.2.2: since 0.2.3, npx zlens ci init writes this workflow for you, pinned to your ZLens version.

npx zlens ci init

This writes .github/workflows/zlens-eval.yml at the root of the git repository:

name: ZLens eval

on:
  pull_request:
  push:
    branches: [main]

permissions:
  contents: read

jobs:
  eval:
    name: ZLens eval
    runs-on: ubuntu-latest
    timeout-minutes: 15
    steps:
      - uses: actions/checkout@v5
      - uses: actions/setup-node@v5
        with:
          node-version: "22"
      - name: Routing eval
        run: npx -y --package=@zlens/cli@0.2.9 zlens eval . --min-route-accuracy 1 --min-refusal 1

The CLI is pinned to the version that wrote the file (0.2.9 here). Run zlens ci init --force to move to a newer one.
There is no install step. The sample ships no lockfile (it ignores package-lock.json), so npm ci would fail, and npx needs none.
When the ZLens project is in a subfolder of the repository, the job gets working-directory: <that folder>.
The job runs on every pull request. To run it only when ZLens files change, add paths under pull_request using your layout, for example domains/**, blocks/**, eval/**, semantic-layer/** and dql.config.json (prefixed with the project folder when it is nested).

Commit the workflow, then make the check required: Settings → Branches → Branch protection rules for main → Require status checks to pass before merging → add ZLens eval.

Optional — `zlens agent eval` in replay mode¶

Video · 0:50Test the real answers

zlens agent eval scores the full answer: the route, the trust label, the SQL and, with --execute, the rows. It always drives a running workbench (--via runtime, the default and only driver), so in CI it needs more than zlens eval:

A warehouse. The workbench answers against your connection. For the Jaffle sample, that means building the dbt project first (dbt seed and dbt build).
Recorded cassettes. Record the suite once against a real provider: start the workbench with ZLENS_EVAL_CASSETTE_DIR=test-cassettes/agent-evals and ZLENS_EVAL_CASSETTE_MODE=record, run the suite, and commit test-cassettes/. Recording needs provider credentials; replay does not.
The workbench in replay mode, then the suite.

The suite is a YAML file of questions and what each answer should be, for example agent-evals.yml:

cases:
  - name: certified revenue by month
    question: "How has revenue changed by month?"
    expected:
      kind: certified
      route: certified
      certification: certified
  - name: orders per store
    question: "How many orders per store?"
    expected:
      kind: uncertified
      route: generated_sql
      certification: analyst_review_required
  - name: unanswerable refuses
    question: "What is our employee churn?"
    expected:
      kind: no_answer

When every case passes, the report ends with lines such as:

3/3 eval case(s) passed.
Certified hit rate: 100%
…
Safe refusal rate: 100%

The workflow steps:

      - name: Start the workbench (replay)
        env:
          ZLENS_EVAL_CASSETTE_DIR: test-cassettes/agent-evals
          ZLENS_EVAL_CASSETTE_MODE: replay
        run: |
          npx -y --package=@zlens/cli@0.2.9 zlens notebook . --no-open --port 3474 > workbench.log 2>&1 &
          for i in $(seq 1 60); do
            curl -sf http://127.0.0.1:3474/api/health && exit 0
            sleep 1
          done
          cat workbench.log; exit 1
      - name: Agent eval
        run: >
          npx -y --package=@zlens/cli@0.2.9 zlens agent eval agent-evals.yml
          --runtime-url http://127.0.0.1:3474 --cassette replay
          --max-false-refusal 0.05 --min-refusal-recall 1

--runtime-url is optional when the workbench runs on the default port 3474.

In replay mode a question whose provider call was not recorded fails; it never reaches a live model. The workbench makes the provider calls, so the environment variables above are what make it replay. --cassette replay checks that: when the workbench's /api/health reports another mode, the eval stops before any case runs and prints the command to start the workbench in replay mode. The --cassette check and the mode in /api/health are there since 0.2.3; 0.2.2 does not check the workbench's mode.

--judge and --min-judge-pass need a live provider, so keep them for a scheduled, credentialed job rather than a pull-request gate.

What `zlens verify` is for¶

zlens verify recompiles the manifest in memory and compares it with the dql-manifest.json that zlens compile wrote in the folder. It is a local check, not a CI gate:

dql-manifest.json is gitignored, and zlens doctor git-hygiene flags it when it is tracked. A clean clone has none, so zlens verify stops with "dql-manifest.json not found".
Running zlens compile and then zlens verify in the same job always passes: it compares a fresh compile with itself.

Use it after zlens compile to confirm the manifest your local tools read (MCP, lineage, the agent index) matches the source:

npx zlens compile .
npx zlens verify .

You should see

  ✓ Manifest verified — no drift between source tree and dql-manifest.json.

Rename a block without recompiling and run it again:

sed -i.bak 's/block "monthly_revenue"/block "monthly_revenue_v2"/' \
  domains/commerce/blocks/monthly_revenue.dql
npx zlens verify .

You should see

  ✗ Manifest drift detected:
    - blocks: removed "monthly_revenue"
    - blocks: added "monthly_revenue_v2"

  Run `zlens compile` to regenerate it.

Both reports go to stdout; the exit code is 1 on drift. Restore the file with mv domains/commerce/blocks/monthly_revenue.dql.bak domains/commerce/blocks/monthly_revenue.dql.

What it compares, from apps/cli/src/commands/verify.ts:

Check	Drift signal
Block, notebook, App, dashboard keys	Added or removed
Semantic-layer metric and dimension keys	Added or removed
Source keys	Added or removed
Per-block SQL	Block SQL changed without recompiling
Per-block status	Certification status changed
Per-block domain	Domain reassigned

It does not compare anything else inside a block (description, owner, examples, outputs), App or dashboard contents beyond their keys, or lineage edges.

Optional — certify and impact checks (need a warehouse)¶

These run against your data, so add them only where CI can reach the connection (for the Jaffle sample, after building the dbt project).

Certify changed blocks. Use a git pathspec so the glob matches both layouts (domains/<domain>/blocks/ and blocks/). --relative keeps the paths relative to the project folder when it is nested:

- name: Certify changed blocks
  run: |
    mkdir -p certify-reports
    for blk in $(git diff --name-only --relative origin/main... -- 'domains/*/blocks/*.dql' 'blocks/*.dql'); do
      npx zlens certify "$blk" --format json > "certify-reports/$(basename "$blk" .dql).json"
    done
- uses: actions/upload-artifact@v4
  with:
    name: certify-reports
    path: certify-reports/

Fetch enough history for origin/main... to resolve (fetch-depth: 0 on actions/checkout). Each report holds blockName, certified, checkedAt, the rules that failed (errors) or warned (warnings), and the test, invariant and DataLex results. Rules that passed are not listed.

Impact of a change. zlens diff <file> --impact reads the compiled lineage, so run zlens compile first; without dql-manifest.json it prints the diff and a note, and exits 0. With it, the command exits 1 only when a changed block invalidates a certified downstream item that --write-recertification did not mark for recertification. Plain zlens diff <file>, without --impact, exits 1 on any change.

What you now have¶

✓ A pull-request gate that replays your golden questions through the router ✓ Golden cases for certified, generated and refused answers ✓ A local check that your compiled manifest matches the source ✓ Optional answer-level and certification checks where CI can reach data

Stuck anywhere? See the troubleshooting guide.
